Are you looking for an upholstery spotting machine that can do the job of a full-size carpet extractor, but is small enough to hold in one hand? Meet the Mytee Lite™ 8070 Heated Carpet Extractor, our best-selling automotive detailing extractor and upholstery machine and the first in the industry to include an on-board heater for max cleaning power. It runs on only one power cord for max convenience wherever you go. At four gallons, it’s perfect for both upholstery spotting and small detailing jobs. The Mytee Lite™ packs performance and versatility into one compact and efficient machine.

The Mytee Lite™ features:
-4 gallon (approx.) capacity tanks
-New and improved single 3-stage motor – 100 CFM, 130? water lift
-1,000-watt in-line heater which produces hot water to quickly break up grease and dirt
-Faucet fill hose for easy fill solution tank
-Recovery tank drain hose
-Compact size and easy-push handle for easy transportation and storage
Includes:
-15ft. 1.25? vacuum and solution hose (Part # 8501).
-Upholstery tool – choose between the 8400P Air Lite™ tool or the stainless steel tool.
-Heatguard™ hosewrap, made of neoprene wetsuit material.
-Pack of 2 Cuties™ QD safety covers (Part # P590)
-Easy-push handle with convenient storage basket.
-A110 Drain Hose.

Body: • Roto-molded polyethylene housing
• 6" (15.2 cm) rear wheels
• 2" (5 cm) locking front casters
Solution Tank: 4 gallon (15.1 L) capacity
Vacuum Tank: 4 gallon (15.1 L) capacity
Vacuum: Single 3-Stage Vacuum Motor
• 100 CFM
• 130" water lift
Pump: Diaphragm Demand Pump
• 120 PSI
• 1.3 GPM
Heater: REAL HEAT™ system – 1,000W – 210ºF maximum
Package Includes: • 4" Upholstery Tool
• 15' Vacuum and Solution Hose Combo
Power Cord: Single 25' (7.6 m) 12/3
Amp Draw (110-120V 60Hz): Cord One: 19 amps
Amp Draw (220-240V 50Hz): Cord One: 9.5 amps
Net Weight: 45 lbs. (20.4 kg)
Machine Dimensions: With handle: 33" x 12" x 36.5" (83.8 cm x 30.5 cm x 92.7 cm), Without handle: 18" x 12" x 28.5" (45.7 cm x 30.5 cm x 72.4 cm)
Shipping Weight: 65 lbs. (29.5 kg)
Shipping Dimensions: 30" x 14" x 37" (76.2 cm x 35.6 cm x 94 cm)
