Minuteman’s MPV®-31 Wide Area Vacuum commands powerful suction to clean large carpeted spaces with efficiency, speed, effortless maneuverability and quiet operation. Durably constructed of rotationally molded polyethylene, the MPV-31 will endure the rigors of heavy use. The lightweight, low-profile design combined with powerful brush action enables the MPV-31 to glide across carpet with ease and delivers impressive results.

Sweeping a wide 30? path, the MPV-31 cleans up to 25,000 sq. ft. per hour and greatly reduces labor time. Further maximizing efficiency, the MPV-31 features an attached telescopic wand and on-board accessory tools for cleaning above-the-floor and hard-to-reach areas.

The MPV-31’s Clean Air Filtration System provides 95% filtration efficiency at 5 microns and easily changes from a 4 to 5-stage filter system with optional cloth filter. The 5-stage system consists of an embossed polyester filter bag, disposable paper bag,foam filter, intake filters on the dual vac motors and an exhaust filter.

-Handle folds for compact storage of this commercial vacuum
-Convenient foot lever for multiple brush height adjustments
-Multiple handle adjustments
-Ergonomic, low-profile design

Air Flow: 21 2 C FM (99 ltrs/sec)
Brush RPM: 1 ,550 RPM
Front Wheels: (2) 2? (5 cm) non-marking , swivel
Front Wheels: (2) 2? (5 cm) non-marking , swivel
Height: 17.5? (44 cm)
Length: 37? (94 cm)
Noise Level: 72 db
Power cord: 75' (23 m), 12-3 gauge , with built-in cord wrap
Rated Voltage: 115 Volt, 60 Hz
Rear Wheels: (2) 12? (30 cm ) non-marking
Vacuum Power: (2) 1 .1 H .P . (802 w atts)
Vacuum Waterlift: 63? (1,600 mm)
Width: 31? (79 cm)
