Ask our Team! The Minuteman E20 is a battery-powered, walk-behind autoscrubber. The ergonomics and ease of use of the E20 provides excellent sightlines and mobility. Reduce fill and empty times with the 12-gallon solution tank and easy-to-clean, 13-gallon recovery tank. The on-board charger allows operators to store and charge the unit with any standard outlet.

Working width: 20 in
Squeegee width: 33 in
Theoretical productivity per hour (pad assist) (disc): 15,000 sq ft (1,393.5 sq m)
Theoretical productivity per hour (traction drive): 27,280 sq ft (2,534.4 sq m)
Working speed (pad assist) (disc): 1.7 mph (2.7 km/h)
Working speed (traction drive): 3.1 mph (5 km/h)
Rated voltage: 24 V
Vacuum flow: 65 cfm
Vacuum waterlift: 45 in (114.3 cm)
Vacuum power: 0.6 hp
Drive motor power (traction drive): 0.2 hp
Brush types: disc, cylindrical
Brush motor(s) power: 0.75 hp
Number of brushes: 1
Brush speed (disc): 180 rpm
Brush speed (cylindrical): 600 rpm
Solution capacity: 12 gal (45.4L)
Recovery capacity: 13 gal (49.2L)
Weight with batteries (pad assist) (disc): 313lbs (142 kg)
Weight without batteries (pad assist) (disc): 203lbs (92.1 kg)
Weight with batteries (traction drive) (disc): 372lbs (168.7 kg)
Weight with batteries (traction drive) (cylindrical): 360lbs (163.3 kg)
Weight without batteries (traction drive): 238lbs (108 kg)

Parts & Support
E20

Interested in purchasing equipment?

Contact our Experts

Need help finding a part?

Ask our Team!
The Minuteman E20 is a battery-powered, walk-behind autoscrubber. The ergonomics and ease of use of the E20 provides excellent sightlines and mobility. Reduce fill and empty times with the 12-gallon solution tank and easy-to-clean, 13-gallon recovery tank. The on-board charger allows operators to store and charge the unit with any standard outlet.

Working width: 20 in
Squeegee width: 33 in
Theoretical productivity per hour (pad assist) (disc): 15,000 sq ft (1,393.5 sq m)
Theoretical productivity per hour (traction drive): 27,280 sq ft (2,534.4 sq m)
Working speed (pad assist) (disc): 1.7 mph (2.7 km/h)
Working speed (traction drive): 3.1 mph (5 km/h)
Rated voltage: 24 V
Vacuum flow: 65 cfm
Vacuum waterlift: 45 in (114.3 cm)
Vacuum power: 0.6 hp
Drive motor power (traction drive): 0.2 hp
Brush types: disc, cylindrical
Brush motor(s) power: 0.75 hp
Number of brushes: 1
Brush speed (disc): 180 rpm
Brush speed (cylindrical): 600 rpm
Solution capacity: 12 gal (45.4L)
Recovery capacity: 13 gal (49.2L)
Weight with batteries (pad assist) (disc): 313lbs (142 kg)
Weight without batteries (pad assist) (disc): 203lbs (92.1 kg)
Weight with batteries (traction drive) (disc): 372lbs (168.7 kg)
Weight with batteries (traction drive) (cylindrical): 360lbs (163.3 kg)
Weight without batteries (traction drive): 238lbs (108 kg)

Minuteman E20 Parts and Support

The Minuteman E20 is a battery-powered, walk-behind autoscrubber. The ergonomics and ease of use of the E20 provides excellent sightlines and mobility. Reduce fill and empty times with the 12-gallon solution tank and easy-to-clean, 13-gallon recovery tank. The on-board charger allows operators to store and charge the unit with any standard outlet.

Working width: 20 in
Squeegee width: 33 in
Theoretical productivity per hour (pad assist) (disc): 15,000 sq ft (1,393.5 sq m)
Theoretical productivity per hour (traction drive): 27,280 sq ft (2,534.4 sq m)
Working speed (pad assist) (disc): 1.7 mph (2.7 km/h)
Working speed (traction drive): 3.1 mph (5 km/h)
Rated voltage: 24 V
Vacuum flow: 65 cfm
Vacuum waterlift: 45 in (114.3 cm)
Vacuum power: 0.6 hp
Drive motor power (traction drive): 0.2 hp
Brush types: disc, cylindrical
Brush motor(s) power: 0.75 hp
Number of brushes: 1
Brush speed (disc): 180 rpm
Brush speed (cylindrical): 600 rpm
Solution capacity: 12 gal (45.4L)
Recovery capacity: 13 gal (49.2L)
Weight with batteries (pad assist) (disc): 313lbs (142 kg)
Weight without batteries (pad assist) (disc): 203lbs (92.1 kg)
Weight with batteries (traction drive) (disc): 372lbs (168.7 kg)
Weight with batteries (traction drive) (cylindrical): 360lbs (163.3 kg)
Weight without batteries (traction drive): 238lbs (108 kg)

Parts

  • Product
  • Qty in Cart
  • Quantity
  • Price
  • Subtotal
  • ships same day
    Non-OEM
    - 50amp charger plug SB50 with pins (red) 991-9284

    50amp charger plug SB50 with pins (red) 991-9284

    $6.47
    Matches:164-0833170-1404175-2041175-7491202-0359204354206-0717206-071823-9-209-123-9-20912392091272-96643BY214-2574-2594096666053876331G16W05670060450342572700011727000128.663-411...
    991-9284
    $6.47
    Qty in Cart: 0
    Price:
    $6.47
    Subtotal:
  • OEM
    210142 - Pedal pad 174-0102

    Pedal pad 174-0102

    $8.44
    Specifications:Weight: 0.087 poundsMatches:210142762294MCH86770330Commonly purchased together:Fits on:Minuteman E20Minuteman 260Bulldog Scrubbers WD20Minuteman 200Minuteman 200Minuteman 170Minuteman LUMINA 20Minuteman 200Bulldog Scrubbers WD26Minuteman...
    174-0102
    $8.44
    Qty in Cart: 0
    Price:
    $8.44
    Subtotal:
  • ships same day
    Non-OEM
    - 12V 105Ah wet battery (SNSR) 162-0011

    12V 105Ah wet battery (SNSR) 162-0011

    $291.50
    Do you also need battery jumper cables? If so, add part number 998-0010.Specifications:Length: 12.63 in Width: 6.75 in Height: 9.38 in Weight: 58 poundsAmp Hours: 105Voltage: 12Chemical Makeup:...
    162-0011
    $291.50
    Qty in Cart: 0
    Price:
    $291.50
    Subtotal:
  • OEM
    - Electrical panel assembly 274-9186

    Electrical panel assembly 274-9186

    $584.25
    Matches:74767091077690Commonly purchased together:May fit on these models - select model and diagram to confirmMinuteman E20Bulldog Scrubbers WD20Minuteman E17Minuteman H20
    274-9186
    $584.25
    Qty in Cart: 0
    Price:
    $584.25
    Subtotal:
  • ships same day
    OEM
    - 8.5 inch tire foam filled 274-7909

    8.5 inch tire foam filled 274-7909

    $241.05
    Specifications:Weight: 2.5 poundsSize: 8.5Type: FixedStyle: Foam FilledColor: YellowMatches:172518174-7159200172-2200172288071350K-172518K-172528Commonly purchased together:Fits on:Minuteman E20Bulldog Scrubbers WD20Bulldog Scrubbers WD26Minuteman...
    274-7909
    $241.05
    Qty in Cart: 0
    Price:
    $241.05
    Subtotal:
  • OEM
    - Solenoid mount assembly 274-7151

    Solenoid mount assembly 274-7151

    $151.67
    Matches:17210491069030Commonly purchased together:May fit on these models - select model and diagram to confirmMinuteman E20Bulldog Scrubbers WD20Bulldog Scrubbers WD26Minuteman E17Minuteman E20 SPORTMinuteman ECO 26Minuteman H20
    274-7151
    $151.67
    Qty in Cart: 0
    Price:
    $151.67
    Subtotal:
  • OEM
    - Brush deck skirt 274-6772

    Brush deck skirt 274-6772

    $107.36
    Matches:172384Commonly purchased together:Fits on:Minuteman E20Bulldog Scrubbers WD20Bulldog Scrubbers BD20Minuteman E20 SPORT
    274-6772
    $107.36
    Qty in Cart: 0
    Price:
    $107.36
    Subtotal:
  • OEM
    - Spray jet assembly 274-5537

    Spray jet assembly 274-5537

    $66.94
    Matches:172312Fits on:Minuteman E20Minuteman H20
    274-5537
    $66.94
    Qty in Cart: 0
    Price:
    $66.94
    Subtotal:
  • OEM
    - SQ SIDE PAS 14/E20C 274-5292

    SQ SIDE PAS 14/E20C 274-5292

    $22.18
    Matches:931235Commonly purchased together:Fits on:Minuteman E20Minuteman PORT A SCRUBMinuteman H20
    274-5292
    $22.18
    Qty in Cart: 0
    Price:
    $22.18
    Subtotal:
  • OEM
    - Directional switch 274-4726

    Directional switch 274-4726

    $36.89
    Matches:74820191063440Commonly purchased together:Fits on:Minuteman E20Bulldog Scrubbers WD20Bulldog Scrubbers WD26Minuteman E17Minuteman E20 SPORTMinuteman ECO 26Minuteman H20
    274-4726
    $36.89
    Qty in Cart: 0
    Price:
    $36.89
    Subtotal:
  • OEM
    - IDLER PULLEY, BRUSH 274-4623

    IDLER PULLEY, BRUSH 274-4623

    $38.46
    Matches:3130075318009191141630Commonly purchased together:Fits on:Minuteman E20Minuteman PORT A SCRUBMinuteman H20
    274-4623
    $38.46
    Qty in Cart: 0
    Price:
    $38.46
    Subtotal:
  • OEM
    - Bearing 274-3331

    Bearing 274-3331

    $21.54
    Specifications:Length: 1 in Width: 1 in Height: 0.25 in Matches:87501191077320Commonly purchased together:Fits on:Minuteman E20Minuteman PORT A SCRUBMinuteman H20
    274-3331
    $21.54
    Qty in Cart: 0
    Price:
    $21.54
    Subtotal:
  • OEM
    - Hose 3/8 X 22 1/2 inch reinforced nylon 274-3007

    Hose 3/8 X 22 1/2 inch reinforced nylon 274-3007

    $19.27
    Specifications:Inside Diameter: 0.375 INLength: 22.5 INNumber of Cuffs: 1Used for: SolutionConstruction Type: Braided or reinforcedMaterial: NylonColor: GrayMatches:172198Commonly purchased together:May fit on these models - select model and diagram to...
    274-3007
    $19.27
    Qty in Cart: 0
    Price:
    $19.27
    Subtotal:
  • OEM
    - Drive hub 274-2649

    Drive hub 274-2649

    $13.92
    Specifications:Weight: 0.25 poundsMatches:011729109.111-683.09054181491116830Commonly purchased together:May fit on these models - select model and diagram to confirmMinuteman E20Bulldog Scrubbers WD20Minuteman E17Bulldog Scrubbers BD20Minuteman E20...
    274-2649
    $13.92
    Qty in Cart: 0
    Price:
    $13.92
    Subtotal:
  • OEM
    - Solution control valve kit 274-9814

    Solution control valve kit 274-9814

    $88.86
    Matches:1725799.113-292.091132920Commonly purchased together:Fits on:Minuteman E20Bulldog Scrubbers WD20Bulldog Scrubbers WD26Minuteman E17Minuteman E20 SPORTMinuteman ECO 26Minuteman H20
    274-9814
    $88.86
    Qty in Cart: 0
    Price:
    $88.86
    Subtotal:
  • OEM
    - Squeegee cable assembly 274-4152

    Squeegee cable assembly 274-4152

    $31.92
    Matches:17238191040450Commonly purchased together:May fit on these models - select model and diagram to confirmMinuteman E20Bulldog Scrubbers WD20Bulldog Scrubbers WD26Minuteman E17Bulldog Scrubbers BD20Minuteman E20 SPORTMinuteman ECO 26Minuteman H20
    274-4152
    $31.92
    Qty in Cart: 0
    Price:
    $31.92
    Subtotal:
