The B 80 battery powered scrubber drier offers a variety of battery options (24 V, 225, 260 Ah and 255 Ah AGM). With brush head and disc brushes, fully automatic squeegee raising and lowering function, 30" working width, large LCD color display, traction drive and KIK key system for protection against incorrect operation. Additional features include: eco!efficiency mode extends battery life, tank rinsing system for automatic cleaning of the dirty water tank without splash back as well as auto-fill function for convenient filling of the water tank. FACT technology, controls the speed of the roller brush and can be adjusted for different cleaning applications. Power Clean - 100% power, for stubborn dirt and polishing. Whisper Clean - 60% power, reduces noise levels and ensures longer working intervals with low power consumption. Fine Clean - 40% power, optimum for cleaning gray film from stoneware tiles in conjunction with green roller brush.

-SImple handling thanks to clear control elements with color coding
-Simplified use and shortened teach in time
-The contact pressure can be adjusted electrically
-Perfect adjustment of the contact pressure to the cleaning requirements
-The contact pressure is adjusted automatically
-Perfect solution on every floor


Brush working width (in): 26 / 30
Vacuum working width (in): 37
Max. area performance (ft²/hr): 24219
Fresh / waste water tank (gal): 21.13 / 21.13
Brush speed (rpm): 600 / 1400
Amps (W): max. 2200
Traction motor (W): 575
Dimensions (L x W x H) (in) : 61.02 x 31.85 x 45.43
