Clarke (Alto) VISION 38I Parts, Diagrams, Manuals and more

Interested in purchasing equipment?

Need help finding a part?

Ask our Team!

Parts
Diagrams
Docs

Motor, Vac 1HP (67kw) three stage tangential discharge
Power Supply 36 volt (6-6V batteries) 250AH, 330AH, or 330AH
Solution Tank 3) 30 gallon (114 liter)
Recovery Tank 30 gallon (114 liter)
Parabolic Squeegee 46 inches
Motors, Brush (2) 1 hp PM (.74kw)
Motor Traction .50 hp PM (.37kw)
Drive Train Direct Drive, Roller Chain
Brushes (2) 19 inch (48cm) w/1" (3 cm) overlap
Brush Speed 200 rpm
Brush Pressure 165 lbs
Speed, Forward 3 speeds to 220ft/min.
Speed, Reverse 2 speeds to 170ft/min.
Drive Wheel 12"x6" (30x15cm)
Charger 36V, 25A, 115V/60hz
Length 65 inches (165cm)
Width 40.5 inches (103 cm)
Height 43 inches (109 cm)
Cleaning Rate 42,000 sq ft/hr (3,901 sq. m/hr)
Cleaning Swath 38 inch (97 cm)
Grade Cleaning 5° Incline
Weight w/Batteries (330AH) 1,230 lbs.
Shipping Weight w/batteries(330AH) 1,340 lbs.

Clarke (Alto) VISION 38I Parts and Support

Floor Pad Selection Guide

Parts
Diagrams
Docs

Parts

Product
Qty in Cart
Quantity
Price
Subtotal

OEM

Gear shaft 164-0353

MSRP:

$231.50

Was:

Specifications:Weight: 1.45 poundsMatches:33-112-133-112133-9-112-133-9-11213311213391121Fits on:Tennant 5680Tennant T3Nilfisk-Advance WARRIOR 34RSTNSS Enterprises WRANGLER 3330Clarke (Alto) ENCORE S20NSS Enterprises WRANGLER 33 F/BNSS Enterprises...

MSRP:

$231.50

Was:

Qty in Cart: 0

Price:

MSRP:

$231.50

Was:

Subtotal:
OEM

Top rotor bearing 164-0329

MSRP:

$28.05

Was:

Specifications:Weight: 0.125 poundsMatches:164-0646164-1145164-1301164-306527-753-127-753127-9-753-127-9-7531277531279753150-204-150-204150-9-204-150-9-20415020415092041May fit on these models - select model and diagram to confirmTennant 5680Tennant...

MSRP:

$28.05

Was:

Qty in Cart: 0

Price:

MSRP:

$28.05

Was:

Subtotal:
Non-OEM

Cable assembly with plug 998-0057

MSRP:

$45.98

Was:

Specifications:Weight: 0.1 poundsMatches:170-009141140ANSOLE CABLE KITAlternative items:Below are other options that may meet your needs.(k) CONSOLE CABLE ASSY. (OBSOLETE)$58.00993-2328Fits on:NSS Enterprises WRANGLER 3330NSS Enterprises WRANGLER 33...

MSRP:

$45.98

Was:

Qty in Cart: 0

Price:

MSRP:

$45.98

Was:

Subtotal:
ships same day

Non-OEM

Clutch plate with brush holder spring 996-0336

MSRP:

$57.14

Was:

Includes brush holder spring.Specifications:Weight: 0.762 poundsMatches:170-0203170-7430833802G-100G100Alternative items:Below are other options that may meet your needs.GIMBAL-BRUSH$87.30993-0217Commonly purchased together:May fit on these models -...

MSRP:

$57.14

Was:

Qty in Cart: 0

Price:

MSRP:

$57.14

Was:

Subtotal:
ships same day

OEM

Squeegee blade rear tan gum rubber 33 inch 170-7197

MSRP:

$54.11

Was:

Specifications:Weight: 0.425 poundsMatches:30946AAlternative items:Below are other options that may meet your needs.BLADE, TAN GUM (QBA) 2 inchx3/16 inchx32-1/2 inch$19.20993-0170Commonly purchased together:May fit on these models - select model and...

MSRP:

$54.11

Was:

Qty in Cart: 0

Price:

MSRP:

$54.11

Was:

Subtotal:
ships same day

OEM

O-ring 170-0273

MSRP:

$7.67

Was:

Specifications:Weight: 0.006 poundsMatches:170-603453878A83730486708660Fits on:Clarke (Alto) ENCORE S20Clarke (Alto) ENCORE S-33XPClarke (Alto) IMAGE 16IClarke (Alto) ENCORE S-28XPClarke (Alto) FOCUS S33Clarke (Alto) BOOST 28Clarke (Alto) IMAGE...

MSRP:

$7.67

Was:

Qty in Cart: 0

Price:

MSRP:

$7.67

Was:

Subtotal:
OEM

Squeegee blade front black notched 33 inch (OBSOLETE) 170-1840

Call for availability

Specifications:Weight: 0.337 poundsMatches:30947AAlternative items:Below are other options that may meet your needs.BLADE, NEO (QBA) 1-7/8 inchx1/8 inch35-7/8 inch-8 No$13.10993-0152Commonly purchased together:May fit on these models - select model and...

MSRP:

$44.58

Was:

Qty in Cart: 0

Price:

MSRP:

$44.58

Was:

Subtotal:
OEM

Squeegee blade 35 7/8 inch gum rubber front (black) 170-0158

MSRP:

$35.60

Was:

Front squeegee blade fits Alto-Clarke Encore and Focus 28 inch (S and L standard models) and Vision 26I. Does not fit the Encore XP models.Specifications:Weight: 0.462 poundsMatches:170-072230914AAlternative items:Below are other options that may meet...

MSRP:

$35.60

Was:

Qty in Cart: 0

Price:

MSRP:

$35.60

Was:

Subtotal:
OEM

Squeegee blade 38 1/4 inch gum rubber rear (tan) 170-0152

MSRP:

$49.63

Was:

Rear squeegee blade fits Alto-Clarke Encore and Focus 28 inch (S and L standard models) and Vision 26I. Does not fit the Encore S-28XP.Specifications:Weight: 0.5 poundsMatches:30912AAlternative items:Below are other options that may meet your needs...

MSRP:

$49.63

Was:

Qty in Cart: 0

Price:

MSRP:

$49.63

Was:

Subtotal:
ships same day

Non-OEM

36V 1.0HP brush motor assembly with gear box 991-8524

MSRP:

$1,044.51

Was:

Specifications:Voltage: 36Horsepower: 1Matches:1069561222255390-222245036A45036B7427148.660-916.086609160F755401M36100GAlternative items:Below are other options that may meet your needs.MOTOR 1 HP W/GEARBOX,45036B$941.00993-0273Commonly purchased...

MSRP:

$1,044.51

Was:

Qty in Cart: 0

Price:

MSRP:

$1,044.51

Was:

Subtotal:
OEM

Hose 170-7018

MSRP:

$10.85

Was:

Specifications:Weight: 0.01 poundsMatches:170-0199170-0240272-991030428A30429A30453A86729860Commonly purchased together:May fit on these models - select model and diagram to confirmClarke (Alto) ENCORE S-33XPNilfisk-Advance SC750Clarke (Alto) ENCORE...

MSRP:

$10.85

Was:

Qty in Cart: 0

Price:

MSRP:

$10.85

Was:

Subtotal:
Non-OEM

Plastic plate only (for 991-2207) (OBSOLETE) 991-2212

Call for availability

Specifications:Weight: 0.087 poundsMatches:-2-PFits on:Clarke (Alto) LEADER 2400 SIIClarke (Alto) VISION 26IClarke (Alto) VISION 38IClarke (Alto) LEADER 2400D SIIClarke (Alto) VISION 32IClarke (Alto) Leader 3200 SII

MSRP:

$12.70

Was:

Qty in Cart: 0

Price:

MSRP:

$12.70

Was:

Subtotal:
