Operators of the Ultra Speed® 20 will sense a whole new feel and experience when burnishing. A more rigid frame and nine vibration isolators have turned the operation of the Ultra Speed 20 into the smoothest burnishing experience in the market.
With an updated, double-pivot pad-driver design, the Ultra Speed 20 burnishing pad stays in alignment and allows the pad to follow the floor contours, leaving a more consistent gloss. Combining the pad-driver design with the self-regulating pad pressure, operators have an easy use, battery walk-behind burnisher that saves labor time and dollars.
Adding to the ease of operation is the self-lowering burnishing deck. When the palm switches on the handle are activated, the burnishing deck automatically lowers to the floor. When the palm switches are released, the deck automatically returns to a raised position. Simple controls also minimize training time of operators.
Choose from either wet batteries for dependable long run time, or maintenance-free AGM gel type batteries for an even longer run time. The onboard battery charger allows for convenient charging at any 120-volt outlet so that operators don’t need to return the machine to a storage or changing area.
Safety isn’t sacrificed for a price and performance. An angle-activated safety switch keeps the machine from starting when tipped back in the pad change position. Superior mobility and line of site during operation add to its safety when in operation.
The best passive dust control in the market is included on all models, which contributes to improve indoor air quality during operation. A felt seal contains all dust within a specially designed shroud, directing it into a dual-port, disposable filter bag.
The Ultra Speed 20 battery burnisher delivers the smooth performance, consistent shine, and cleaner indoor air quality that is demanded by today’s customers.

• 20 inch burnishing path powered by a 2.5 hp motor
• Self-regulating pad pressure no adjustment required
• Non-traction or power traction drive
• Class leading passive dust control
• Easy tip back feature for convenient pad changes
• Wet cell or AGM batteries
• Onboard charger (standard)

Brushing path/Pad diameter: 20 in(52 cm)
Drive-Traction or Non-traction: Non-traction
Power supply/batteries: 36V/ 3- 200 Ah Wet
Pad rpm (on the floor): 2,000 RPM
Low battery protection: Standard on All Models
Dust control: Passive on All Models
Pad motor: 2.5 hp (1.9 kW)
Transaxle Traction motor: N/A
Pad pressure: Self regulating up to 30 lbs (13kg)- All Models
Speed forward/reverse: N/A
Sound level : 68 dB A
Drive wheels: 1.62 in x 8 in (4cm x 20cm)
Onboard charger: 36V, 25 A DC, 85-265 V/ 45-65 Hz AC
Dimensions: 53.5 in x 23 in x 42 in (136 cm x 58 cm x 106 cm)
