Clarke (Alto) SA40 Parts and Support

• Parts
• Diagrams
• Manuals

A cost-efficient cleaning solution
Clarke has been helping cleaning professionals increase effectiveness and productivity for 100 years. Now we pleased to introduce the SA40 stand on scrubber to further enhance your cleaning productivity. Designed to deliver reliable cleaning performance, the SA40 stand-on scrubber provides a flexible, extremely maneuverable and compact solution for small to medium-sized areas.

Maximum productivity
Clarke has set the standard for robust, productive, easy to use and reliable cleaning equipment. The Clarke SA40 is designed with a large 12 gallon solution tank and low flow rate, which can provide up to 75 minutes of scrub time without refiling, so you will spend more time cleaning. The SA40 is also engineered to provide increased down pressure at 88 pounds to enable to you to enjoy maximum clean in a single pass.

Consistent, easy cleaning
The SA40 ensures consistent, reliable cleaning with solution flow rate control right at your fingertips. Select from low, medium or high flow rates to match the job at hand without stopping the machine. This not only minimizes cleaning solution waste but also reduces time spent on dump and refills. For simple operation, all scrubbing parameters- brush pressure, solution flow and vacuum- are all controlled with individual buttons, and are clearly displayed on the easy-to-read, LCD graphical display.

TruBlue sustainability
With the SA40 you can enjoy a high level of cleaning performance without sacrificing sustainability. The SA40 is designed to allow you to clean with minimal consumption of detergent and water so that real savings can be gained without compromising performance or the environment. All Clarke auto scrubbers feature important benefits such as low noise levels, enhanced user ergonomics, onboard chargers and superior pickup to ensure you are left with clean, dry and safe floors.

• High Productivity
• Excellent Maneuverability
• Flexible Cleaning to Address Varying Soil Levels
• Designed to Provide Maximum Clean and Safety
• Extremely Quiet for Daytime Cleaning

Scrub Head Disc
Scrub Path 20 in (51 cm)
Solution Tank 12 gal (45 L)
Recovery Tank 12.5 gal (47 L)
Machine Voltage 24 V
Vacuum Motor 0.66 hp (492 W) 3-stage
Scrub Motor 0.51 hp (380 W)
Scrub Motor RPM 140
Low Scrub Pressure Max 51 lb (23 kg)
High Scrub Pressure Max 88 lb (40 kg)
Drive Motor 0.375 hp (280 W)
Max Transport Speed 3 mph (4.8 kph)
Max Scrub Speed 2.6 mph (4.2 kph)
Max Coverage 26,400 ft2 (2,453 m2 )
Max Sound Pressure Level (IEC 60704-1) 63 dB A / .029344 µPa
Minimum Aisle Turn Width 59.5 in (151 cm)
Squeegee Width 26.5 in (67.3 cm)
Dimensions (L x W x H) 48.5 x 24 in x 52.5 in (123.2 x 61 x 133.4 cm)
