Moving beyond the mop A floor scrubber that looks and works like an upright vac? Now this is a revolution in cleaning! For generations the mop and bucket was the only option for scrubbing small spaces, but spreading dirty water around is neither effective nor sanitary. That’s why Clarke developed the MA10™ 12E Upright Scrubber.

The faster way to cleaner floors Not only does the compact, lightweight design of the MA10 12E Scrubber allow you to clean very tight areas—just like an upright vacuum—but it gets the job done fast and effectively. And unlike mops and buckets, the Clarke MA10 uses only clean water to clean your floors. It immediately vacuums up the dirty water, leaving your floors cleaner and more hygienic.

Convenient, easy-to-use upright design cleans small, high-traffic spaces quickly and effectively Single-pass, scrub-and-dry action allows quick access to cleaned areas, unlike mopping Two-hand grip plus lightweight design make the Clarke MA10 12E Scrubber easy to maneuver and a snap to carry anywhere Lay-flat design and manual suction hose allow you to clean even the most hard-to-reach areas Removable solution tank dispenses only clean solution to floor, unlike mops and buckets that “clean” with dirty water

Cleaning width: 12.2 in (31 cm)
Performance per hour (theoretical / practical): 2,434 / 1,590 sq ft (226 / 147 sq m)
Brush speed (RPM): 2,100 RPM
Squeegee width: 12.6 in (32.1 cm)
Solution capacity: 0.8 gal (3 L)
Waterlift, max. (Inches H2O): 72 in H2O (180 mBar)
Airflow ft: 3/min (L/SEC)33.9 CFM (16 L/sec)
Solution flow: 0/0.05 gal/min (0/0.2 L/min)
Run time per tank: Up to 16 min
Recovery tank capacity gal (l): 1 gal (4 L)
Vacuum motor: 0.94 hp (700 W)
Dimensions L x W x H: 15.75 x 14.2 x 45.3 in (40 x 36 x 115 cm)
Weight (with Cord): 26.5 lb (12 kg) / 33.1 lb (15 kg) w/ solution
Sound level: 72 ± 2 dB A
Cord length (ft): 33 ft (10 m)
