FOCUS II 28 DISC

FOCUS II 28 DISC

Clarke (Alto) FOCUS II 28 DISC

Interested in purchasing equipment?

Contact our Experts!

Need help finding a part?

Ask our Team! The Clarke FOCUS II 28 DISC is a battery-powered, walk-behind autoscrubber. With built-in BOOST Technology, the FOCUS line of machines are the only ones capable of removing floor finish without the need for chemicals. With an easy-to-access battery compartment, maintenance and installation is easy.

Working width: 28 in (71.1 cm)
Brush size: 14 in (36 cm) (2)
Brush motor power: 0.75 hp (0.56 kW) (2)
Brush moto speed: 200 rpm
Brush pressure: 80lbs (36 kg), 150lbs (68 kg)
Squeegee width: 35 in (89 cm)
System voltage: 24 V
Vacuum motor power: 0.75 hp (0.56 kW)
Vacuum stages: 3-stage
Solution tank capacity: 23gal (87L)
Recovery tank capacity: 23gal (87L)
Solution flow rate: 0-1gpm (0-3.8L/min)
Propel speed, forward (variable): 3 mph (4.8 km/hr)
Propel speed, reverse (variable): 2 mph (3.2 km/hr)
Sound level: 65 dB(A)
Dimensions, Length x Width x Height: 62 x 30 x 44 in (157.5 x 76.2 x 111.8 cm)

Parts & Support
FOCUS II 28 DISC

Interested in purchasing equipment?

Contact our Experts

Need help finding a part?

Ask our Team!
The Clarke FOCUS II 28 DISC is a battery-powered, walk-behind autoscrubber. With built-in BOOST Technology, the FOCUS line of machines are the only ones capable of removing floor finish without the need for chemicals. With an easy-to-access battery compartment, maintenance and installation is easy.

Working width: 28 in (71.1 cm)
Brush size: 14 in (36 cm) (2)
Brush motor power: 0.75 hp (0.56 kW) (2)
Brush moto speed: 200 rpm
Brush pressure: 80lbs (36 kg), 150lbs (68 kg)
Squeegee width: 35 in (89 cm)
System voltage: 24 V
Vacuum motor power: 0.75 hp (0.56 kW)
Vacuum stages: 3-stage
Solution tank capacity: 23gal (87L)
Recovery tank capacity: 23gal (87L)
Solution flow rate: 0-1gpm (0-3.8L/min)
Propel speed, forward (variable): 3 mph (4.8 km/hr)
Propel speed, reverse (variable): 2 mph (3.2 km/hr)
Sound level: 65 dB(A)
Dimensions, Length x Width x Height: 62 x 30 x 44 in (157.5 x 76.2 x 111.8 cm)

Clarke (Alto) FOCUS II 28 DISC Parts and Support

The Clarke FOCUS II 28 DISC is a battery-powered, walk-behind autoscrubber. With built-in BOOST Technology, the FOCUS line of machines are the only ones capable of removing floor finish without the need for chemicals. With an easy-to-access battery compartment, maintenance and installation is easy.

Working width: 28 in (71.1 cm)
Brush size: 14 in (36 cm) (2)
Brush motor power: 0.75 hp (0.56 kW) (2)
Brush moto speed: 200 rpm
Brush pressure: 80lbs (36 kg), 150lbs (68 kg)
Squeegee width: 35 in (89 cm)
System voltage: 24 V
Vacuum motor power: 0.75 hp (0.56 kW)
Vacuum stages: 3-stage
Solution tank capacity: 23gal (87L)
Recovery tank capacity: 23gal (87L)
Solution flow rate: 0-1gpm (0-3.8L/min)
Propel speed, forward (variable): 3 mph (4.8 km/hr)
Propel speed, reverse (variable): 2 mph (3.2 km/hr)
Sound level: 65 dB(A)
Dimensions, Length x Width x Height: 62 x 30 x 44 in (157.5 x 76.2 x 111.8 cm)

Parts

  • Product
  • Qty in Cart
  • Quantity
  • Price
  • Subtotal
  • Non-OEM
    26040-83 AGM - 24V 20amp AGM battery charger with small SB50 red plug 162-5070

    24V 20amp AGM battery charger with small SB50 red plug 162-5070

    $429.37
    Specifications:Chemical Makeup: AGMCharger Plug Color: RedMatches:162-5060162-507026040-83 AGM7006045036789.110-410.09.114-416.09114416098486810Alternative items:Below are other options that may meet your needs.CHARGER 24V 20A SCR, SEALED (50A RED)$681...
    $429.37
    Qty in Cart: 0
    Price:
    $429.37
    Subtotal:
  • OEM
    56390072 - 24V brush motor 272-9948

    24V brush motor 272-9948

    $1,179.74
    $1,179.74
    Qty in Cart: 0
    Price:
    $1,179.74
    Subtotal:
  • OEM
    56380158 - Flange kit 272-9820

    Flange kit 272-9820

    $127.61
    Matches:3801585638015891046870May fit on these models - select model and diagram to confirmNilfisk-Advance SC750Clarke (Alto) FOCUS II BOOST 28Clarke (Alto) FOCUS II BOOST 32Clarke (Alto) FOCUS II 28 DISCClarke (Alto) FOCUS II 26 DISCNilfisk-Advance...
    $127.61
    Qty in Cart: 0
    Price:
    $127.61
    Subtotal:
  • ships same day
    OEM
    909 5286 000 - Gasket 272-8076

    Gasket 272-8076

    $11.57
    $11.57
    Qty in Cart: 0
    Price:
    $11.57
    Subtotal:
  • OEM
    41062A - Jumper harness 272-6607

    Jumper harness 272-6607

    $59.72
    $59.72
    Qty in Cart: 0
    Price:
    $59.72
    Subtotal:
  • OEM
    909 6643 000 - Plate 272-5297

    Plate 272-5297

    $13.17
    $13.17
    Qty in Cart: 0
    Price:
    $13.17
    Subtotal:
  • OEM
    54778A - Adapter cap 270-0349

    Adapter cap 270-0349

    $52.67
    $52.67
    Qty in Cart: 0
    Price:
    $52.67
    Subtotal:
  • OEM
    53721A - Chemical pump 270-0348

    Chemical pump 270-0348

    $651.08
    $651.08
    Qty in Cart: 0
    Price:
    $651.08
    Subtotal:
