Clarke (Alto) EX30 Parts and Support

• Parts
• Diagrams
• Manuals

The EX30 is the result of years of extensive engineering and design experience coming together with customer feedback to create one of the most powerful and user-friendly portable carpet extractors ever made.

The EX30 is designed with end user's needs in mind. Features like upright, dolly design for easy loading, unloading and stair climbing make the EX30 easy to handle by one person. Wand caddy, retractable cord wrap and large rear wheels make the EX30 very easy to transport. For maintenance, it doesn't get any easier than the EX30 pallet design. Simply open the hinged tanks for full access to all internal components on the machine.

But it is the "Easy Transport" features on the EX30 that crown it already as the the king of mobility. A special wand caddy is molded into the design of the machine. A retractable hose wraps holds your vacuum and solution hose. Cord wraps hold your electrical cords. It is the easiest high performance extractor in the world to move through a facility.

For performance, the EX30 has all the power and versatility you expect a Clarke extractor to have and more! Dual vacuums and on-demand 212 ° F heat provide unmatched cleaning power, but don't take our word for it, let the proven performance of the CRI Golf certification speak for the power of the EX30!

• Smart circuit locator
• Heater element
• Low moisture design
• Low noise for daytime-quiet operation
• 12 gallon solution tank
• 10 gallon recovery tank
• Innovative fresh air intake for each vacuum motor, increased durability
• Two handles for easy maneuverability and loading
• Roller handles for easy loading
• Upright dolly design for easy stair climbing
• Wand caddy for easy transport
• 12 inch non-marking wheels
• Low solution filling area for easy filling
• 15 foot high pressure solution line and crush proof vacuum hose (optional 25 foot available)
• 2 cords, each 25 foot detachable 12/3 gauge, hospital grade plugs
• Pressure relief valve
• CRI certified

Vacuum Dual 5.7 in, 3-stage Vac
Shutoff Ball float
Pump Positive displacement adjustable 50-500 psi
Water Lift 200 in
Heat Adjustable to 212° F for carpet extraction, or 145° F for upholstery
Heater 2,000 W
Gauge Glycerin filled pressure gauge
Wand Aqua Wand™ 12 in rotationally molded wand
Dimensions H = 39 in x W = 25 in x L = 33 in
Weight 110 lb
