The Betco Watchman series of automatic scrubbers bring a new dimension to cleaning maintenance. The Watchman 17 offers a compact size for easy maneuvering making it perfect for small to medium size facilities with tight areas. It's simple design and controls make operation easy and reduce operator training. Unique features include hands free pad driver installation and a removable recovery tank, no tools required. A heavy duty squeegee assembly provides maximum water recovery.

-Simple design for easy operation
-Hands free pad driver installation
-Removable recovery tank for easy transport and serviceability
-Durable rotationally molded polyethylene construction

Cleaning path: 17"
Pad driver: (1) 17"
Brush motor: (1) 0.5 hp
Brush pressure: 50 lbs.
Brush speed: 275 RPM
Vacuum motor: 0.5 hp 2-stage
Noise level: 65 dB
Water lift: 48"
Solution control: gravity feed- adjustable
Solution tank: 10 gallon
Recovery tank: 11 gallon
Weight: 155 lbs
Length: 43"
Width: 18" w/o squeegee
Width: 26" w/ squeegee
Height: 38"
Volts: 24 volt system
Batteries: (2) 12 volt
Run time: approximately 3.5 hours
Tires: heavy duty non-marking
Productivity: 15,000 sq. ft/hour
