The patented brush design follows the floor profile and delivers nearly even pressure allocation along the full working width. This results in excellent soil removal. The U-shaped squeegee allows excellent water pick-up along the full working width. Special squeegee blades and a direct suction design allow pick-up of small debris (e.g. cigarette butts)
without clogging.
Productivity and Manoeuvrability
Increased battery capacity coupled with a larger tank and the patented CSD system radically increases productivity. The dual-axle system ensures easy handling and allows excellent manoeuvrability in confined areas.
Ergonomics
The ergonomic handle suits all operators. All functions of the machine can be operated from the working position. The dashboard is self explanatory with minimum training needed and displays all required information.
Maintenance
Colour coded maintenance points increase efficiency and reduce the need for training. Fewer parts to maintain and easy accessibility make the machine extremely service friendly.
-Unbeatable Cleaning Performance
-Increased Productivity and Manoeuvrability
-Excellent Ergonomics
-Simplicity and easy Maintenance
Theoretical performance: 2475 m²/h
Working width: 55 cm
Squeegee width: 75 cm
Solution tank (nomina)l: 52 l
Recovery tank (nominal): 50 l
Normal consumption: 1000 W
Rated voltage: 24 V
Battery capacity: 100 - 140 Ah/C5
Battery automony (nominal): 3.5 h
Machine weight ready for use: 240 kg
Dimensions (L x W x H): 1332x490x1153 mm
Turning circle: 1.33 m
Brush system: 2 x 28 cm
Brush pressure: 46 kg
Cleaning speed / transportation speed: 4.5 / 5.3 km/h
Cable length of integrated battery charger: 2.5 m
Sound level: 58 dB(A)
Splash water protection: IPX3
Electrical protection class -
Approvals: TÜV, ÖVE Interactive Service Guide
