» Compact design provides powerful scrubbing in congested areas
» Two counter-rotating brushes with variable cleaning pressure, up to 88 lbs
» Two squeegees for pick-up in forward or reverse
• Increased Productivity
» Large 2.5 gallon tanks
» Solution and recovery tanks are easy to fill, empty and clean
» Easy to understand control system with ergonomic handle
» No tool brush and squeegee removal for easy maintenance
• Versatility
» Cleaning pressure adjustment for effective cleaning on different floor types
» Variety of brushes available for any cleaning application
Working Width: 16" (400mm)
Practical Cleaning Performance: 3,200 ft2/hour (300 m2/hour)
Brushes: Two 16" (400mm) - Cylindrical
Brush Diameter: 3.7" (96mm)
Brush Speed: 660 rpm
Brush Motor: 1.5 hp (1100 watts)
Down Pressure: 88 lbs (40 kg) with full solution tank
Solution Capacity: 2.5 Gallons (10 liters)
Solution Flow: .25-.3 Gallons/min ( 1-1.2 liters/min)
Recovery Capacity: 2.5 Gallons (10 liters)
Vacuum Motor: .6 hp (500w)
Dimensions L x W x H: 20.5" x 18.5" x 15"
(520mm x 470mm x 380mm)
Deck Height (at brush): 15" (380mm)
Weight: 66 lbs (30 kg)
Noise Level: 71 dBA
Warranty: Windsor 10/3/3 Protection Plan.
See full warranty for details.
Windsor Saber Blade 16 (gray) Parts and Support
