» Unique Penetrator vacuum shoe design provides superior solution recovery and faster dry time.
» 20 gallon capacity reduces drains and refills
» Clean 5,000 ft2 per hour
» Easy-to-use controls reduce training time and increases productivity time.
Vacuum Motor: 3 stage, 2 hp (1492 watts), 99 cfm (2.8 m3/min), 117" (297 mm) waterlift
Solution Pump: 100 psi (7 bar), diaphragm style, demand pump
Brush Motor: 1/3 hp (250 watts)
Brush: 18" (46 mm) wide
Brush Speed: 1000 rpm
Drive System: Transaxle
Drive Motor: 1/8 hp (93 watts)
Cleaning Speed: Variable speed, 0–100 ft/min (30.5 m/min)
Cleaning Rate 5,000 ft²/hour (465 m²/hour)
Solution Capacity: 20 gallon (75 ltr)
Recovery Capacity: 20 gallon (75 ltr)
Vacuum Shoe: 22" (56 mm) wide, molded channels, steel exterior
Electrical System: 120 V, 15 amp
Power Cable: 75' (23 m) 12/3 vinyl covered, detachable
Solution Spray: 2 “04” quick change jets
(“02” quick change jets for interim cleaning—optional)
Construction: Powder-coated steel chassis with rotationally-molded
polyethylene tanks
Wheels
Front:Two, 4" (10 mm) dia. casters
Rear:Two, 10" (25 mm) dia. wheels
Weight: 217 lbs (98 kg)
Dimensions (LxWxH): 49" (124 mm) x 22" (56 mm) x 41" (104 mm)
Windsor COMMODORE 20 Parts and Support
» low profile and compact design allow exceptional maneuverability in small areas.
» unique penetrator vacuum shoe design provides superior solution recovery and faster dry time.
» 20 gallon capacity reduces drains and refills
» clean 5,000 ft2 per hour
» easy-to-use controls reduce training time and increases productivity time.
vacuum motor: 3 stage, 2 hp (1492 watts), 99 cfm (2.8 m3/min), 117" (297 mm) waterlift
solution pump: 100 psi (7 bar), diaphragm style, demand pump
brush motor: 1/3 hp (250 watts)
brush: 18" (46 mm) wide
brush speed: 1000 rpm
drive system: transaxle
drive motor: 1/8 hp (93 watts)
cleaning speed: variable speed, 0–100 ft/min (30.5 m/min)
cleaning rate 5,000 ft²/hour (465 m²/hour)
solution capacity: 20 gallon (75 ltr)
recovery capacity: 20 gallon (75 ltr)
vacuum shoe: 22" (56 mm) wide, molded channels, steel exterior
electrical system: 120 v, 15 amp
power cable: 75' (23 m) 12/3 vinyl covered, detachable
solution spray: 2 “04” quick change jets
(“02” quick change jets for interim cleaning—optional)
construction: powder-coated steel chassis with rotationally-molded
polyethylene tanks
wheels
front:two, 4" (10 mm) dia. casters
rear:two, 10" (25 mm) dia. wheels
weight: 217 lbs (98 kg)
dimensions (lxwxh): 49" (124 mm) x 22" (56 mm) x 41" (104 mm)
» unique penetrator vacuum shoe design provides superior solution recovery and faster dry time.
» 20 gallon capacity reduces drains and refills
» clean 5,000 ft2 per hour
» easy-to-use controls reduce training time and increases productivity time.
vacuum motor: 3 stage, 2 hp (1492 watts), 99 cfm (2.8 m3/min), 117" (297 mm) waterlift
solution pump: 100 psi (7 bar), diaphragm style, demand pump
brush motor: 1/3 hp (250 watts)
brush: 18" (46 mm) wide
brush speed: 1000 rpm
drive system: transaxle
drive motor: 1/8 hp (93 watts)
cleaning speed: variable speed, 0–100 ft/min (30.5 m/min)
cleaning rate 5,000 ft²/hour (465 m²/hour)
solution capacity: 20 gallon (75 ltr)
recovery capacity: 20 gallon (75 ltr)
vacuum shoe: 22" (56 mm) wide, molded channels, steel exterior
electrical system: 120 v, 15 amp
power cable: 75' (23 m) 12/3 vinyl covered, detachable
solution spray: 2 “04” quick change jets
(“02” quick change jets for interim cleaning—optional)
construction: powder-coated steel chassis with rotationally-molded
polyethylene tanks
wheels
front:two, 4" (10 mm) dia. casters
rear:two, 10" (25 mm) dia. wheels
weight: 217 lbs (98 kg)
dimensions (lxwxh): 49" (124 mm) x 22" (56 mm) x 41" (104 mm)
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
In the market for a new machine? You can find quality new and reconditioned floor care equipment at one of our vendor partners:
Need a professional? We offer service both virtually and in person.
Learn more
Diagrams
- View all diagrams
- - Extractor Fit All Parts
- - Frequently Replaced Parts
- - Simplified Recovery System
- - Simplified Solution System
- Brush Assembly
- Control Panel Assembly
- Frame Assembly
- Lift Lever - Lower Tower Assembly
- Pump Assembly
- Recovery Tank Assembly
- Solenoid - Manifold Assemblies
- Solution Tank Assembly
- Upper Tower Assembly
- Vacuum Shoe Assembly
- Wiring Diagram
