BACKPACK SPRAYER

32

• Parts
• Diagrams
• Manuals

The Victory Innovations® Professional Cordless Electrostatic Backpack Sprayer is designed to allow the professional to cover up to 23,000 square feet (2,130 square meters) on a single tank of fluid (coverage per tank is determined by internal testing using flow rate and particle size). It is designed to save time and labor and cover more surfaces. Our patented technology adds an electrostatic charge to solutions, allowing them to wrap conductive surfaces with an effective and even coverage. Charged particles envelop all conductive surfaces – shadowed, vertical, and underneath.

-Patented electrostatic charge penetrates chemical providing a thin, even spray pattern on all surfaces
-Removable Easy Fill HDPE tank holds 2.25 gallons / 8.52 L of chemical, allowing you to coat up to 23,000 sq. ft / 2,130 sq. m
-Cordless convenience allows for effortless movement room to room
-3-in-1 nozzle allows you to set particle size to match your application
-4ft / 1.2m hose with quick release valve allows for comfortable reach and maximum maneuverability

Voltage: 16.8V
Warranty: 1yr limited warranty
Battery: 16.8V 3350mAh Lithium-Ion
Weight: 10.0 lbs (29 lbs full) / 4.5 kg (13 kg full)
Optimum Spray Distance: 2 - 6 ft / 0.61 - 1.83 m
Tank Capacity: 2.25 gallons / 8.52 L
Run Time: 4 hours per charge
Nozzle Spray Sizes: 40 micron full cone, 80 micron full cone, 110 micron 120º fan
Charge Time: 180 Minutes
Flow Rate: 40 micron: 3.4 oz / 100.6 mL per minute | 80 micron: 5.1 oz / 150.8 mL per minute | 110 micron: 13.4 oz / 396.3 mL per minute
