EASYSCRUB 2832

57

• Parts
• Diagrams
• Docs

Versatile Performer
With one chassis and four interchangeable scrub decks to select from, the ES2832 Easy Scrub Automatic Scrubber provides four models choices in one machine. Adaptable to meet your cleaning needs, the ES2832 is available with two sizes of interchangeable scrub decks in 28" or 32" coverage, disc or cylindrical, and optional accessories. Constructed of a steel frame and rotationally-molded polyethylene tanks and bumpers, the ES2832 is built to last. The ES2832 is ergonomically designed for operator comfort and ease of use with one button scrub-smart control and an excellent line of sight due to its low profile. With outstanding maneuverability and standard pneumatic studded tires, the ES2832 can make a effortless turn on its own axis while recovering all dispensed water.

Easy Maneuverability
The Minuteman ES2832 scrubber is designed for operator comfort, safety and efficiency. User-friendly control panels and "comfort zone" hand bails are convenient, easy and safe to use. The hand bails allow the operator to hold the handle at any position, reducing hand fatigue.
Due to the low profile design, the operator has an excellent line of sight to the floor in front of the machine. The ES2832 reduces operator fatigue and provides maximum maneuverability and cleaning efficiency.

Safety and Technology
The ES2832 is equipped with a "belly bar" that prevents the operator from being pinned behind the machine when in the reverse mode. Also standard is a color coded LED battery gauge that will let the operator know if any error code faults are coming from the on-board computer. This helps pinpoint any problem for easy and quick repair.

Easy-to-Read Control Panel
The ES2832's control panel has five easy to understand icons, operated with the turn of a selector switch. A one-touch, directional lever, controls forward and reverse operation. The LED battery gauge lets the operator know when the batteries need to be charged.

Easy-to-Adjust Rear Squeegee Assembly
The squeegee assembly utilizes a break-away design in case of impact. Removal of the assembly and the blades requires no tools and is quick and simple. The squeegee is self-tracking and picks up all dispensed water on every turn. The squeegee assembly automatically lowers when the machine is moving forward and raises automatically in reverse. Two caster wheels adjust to provide uniform blade deflection. The pitch of the assembly is also easily adjustable with a turnbuckle system. The front squeegee blade features a slotted and unslotted blade for use on different floor types. The rear squeegee blade is four-sided for maximum extended use.

Durable Construction
The ES2832 is made with a powder coated, epoxy painted, 11 gauge steel frame to resist corrosion. The tanks and bumper are constructed of a heavy-duty rotationally-molded polyethylene. Rugged construction and reliability, a Minuteman hallmark, means that the ES2832 Scrubber us built to last.

-Fully variable solution flow rate
-Spray jets for cylindrical scrub deck, ensure uniform solution distribution on floor
-Disc brushes are center-fed to keep water & chemical contained with more contact time
-Easy-to-adjust two caster wheel adjustment insures proper squeegee setting
-One piece, double wall, rotationally molded bumper can be easily removed for brush head access
-Dirty water drain hose extends to five feet, allowing drainage at the side, rear or front of scrubber
-“Belly Bar” to prevent the operator from being pinned against a wall while machine is in reverse
-Large 12? pneumatic tires grip the surface
-Key switch to ensure authorized personnel use only
-Hour meter
-Large 31 gallon solution tank and 35 gallon recovery tank, provide for less emptying and refilling
-Squeegee swings from side to side, picking up all water on 180 degree turns

Brush Motor & RPM (Cyl): (2) 1 HP 900 rpm
Brush Motor & RPM (Disc): 2 HP dual right angle 300 rpm
Brush Pressure: 2 Settings: Regular & Heavy
Caster Wheels: (2) 5? (13 cm)
Drive Motor: 1/2 HP transaxle
Front Wheels: (2) 12? Pneumatic (30 cm)
Front Wheels: (2) 12? Pneumatic (30 cm)
Height: 46? (116 cm)
Length: 66? (167 cm)
Performance: 33500 ft²/ hr (3112 m²/ hr)
Recovery Capacity: 35 gallons (132 L)
Scrub Brush (Cyl): (2) 31- 1/4 Offset (79 cm)
Scrub Brush (Disc): (2) 16? (40.5 cm)
Scrub Path: 32? (81 cm)
Solution Capacity: 31 gallons (117 L)
Squeegee Width: 47? (119 cm)
Width: 38? (96 cm)
