-Low profile design for cleaning tight, hard-to-reach areas
-Onboard battery charger
-Parabolic squeegee for easy and complete solution pick-up
-Fold-down handle for storage
-Lift-off recovery tank
-Auxiliary charging cable
-Cast aluminum squeegee assembly
-Perfect for small, confined areas such as exam rooms, bathrooms, living rooms, etc.
-Works on all surfaces including hardwood, LVT, ceramic, marble, and granite
Cleaning Path: 15 in (38 cm)
Solution Tank: 3.5 gal (13.5 ltr)
Recovery Tank: 3.5 gal (13.5 ltr)
Brush/Pad Size, Brush Included: 15 in (38cm)
Brush/Pad Pressure: 44.5 lbs (20kg)
Squeegee: 20 in (51cm)
Cleaning Productivity (Max): 8,000 ft2/hr (743 m2/hr)
Drive System: Pad-assist
Wheels, Non-marking Black (2): 10 in (25.4cm)
Brush Motor, rpm Speed: 1/3 hp, 150 rpm (.25kW, 150 rpm)
Vacuum Motor, Waterlift: 1/3 hp, 40 in waterlift (.25 kW, 100 cm waterlift)
Sound Level: 70 dBA
Batteries, Sealed AGM: Two 12V, 33 A/H
Charger, Onboard: 24V, 5 amp
Charger Cord Length: 6 ft (1.8m)
Run Time per Charge: Up to 2 hrs
Machine Weight: 124 lbs (56kg)
Shipping Weight :135 lbs (61kg)
Dimensions (L x W x H): 30 in x 20 in x 21.7 in (77 cm x 50 cm x 55 cm)
Diamond Company Crown G15 Parts and Support
-easy-to-use, fingertip controls
-low profile design for cleaning tight, hard-to-reach areas
-onboard battery charger
-parabolic squeegee for easy and complete solution pick-up
-fold-down handle for storage
-lift-off recovery tank
-auxiliary charging cable
-cast aluminum squeegee assembly
-perfect for small, confined areas such as exam rooms, bathrooms, living rooms, etc.
-works on all surfaces including hardwood, lvt, ceramic, marble, and granite
cleaning path: 15 in (38 cm)
solution tank: 3.5 gal (13.5 ltr)
recovery tank: 3.5 gal (13.5 ltr)
brush/pad size, brush included: 15 in (38cm)
brush/pad pressure: 44.5 lbs (20kg)
squeegee: 20 in (51cm)
cleaning productivity (max): 8,000 ft2/hr (743 m2/hr)
drive system: pad-assist
wheels, non-marking black (2): 10 in (25.4cm)
brush motor, rpm speed: 1/3 hp, 150 rpm (.25kw, 150 rpm)
vacuum motor, waterlift: 1/3 hp, 40 in waterlift (.25 kw, 100 cm waterlift)
sound level: 70 dba
batteries, sealed agm: two 12v, 33 a/h
charger, onboard: 24v, 5 amp
charger cord length: 6 ft (1.8m)
run time per charge: up to 2 hrs
machine weight: 124 lbs (56kg)
shipping weight :135 lbs (61kg)
dimensions (l x w x h): 30 in x 20 in x 21.7 in (77 cm x 50 cm x 55 cm)
-low profile design for cleaning tight, hard-to-reach areas
-onboard battery charger
-parabolic squeegee for easy and complete solution pick-up
-fold-down handle for storage
-lift-off recovery tank
-auxiliary charging cable
-cast aluminum squeegee assembly
-perfect for small, confined areas such as exam rooms, bathrooms, living rooms, etc.
-works on all surfaces including hardwood, lvt, ceramic, marble, and granite
cleaning path: 15 in (38 cm)
solution tank: 3.5 gal (13.5 ltr)
recovery tank: 3.5 gal (13.5 ltr)
brush/pad size, brush included: 15 in (38cm)
brush/pad pressure: 44.5 lbs (20kg)
squeegee: 20 in (51cm)
cleaning productivity (max): 8,000 ft2/hr (743 m2/hr)
drive system: pad-assist
wheels, non-marking black (2): 10 in (25.4cm)
brush motor, rpm speed: 1/3 hp, 150 rpm (.25kw, 150 rpm)
vacuum motor, waterlift: 1/3 hp, 40 in waterlift (.25 kw, 100 cm waterlift)
sound level: 70 dba
batteries, sealed agm: two 12v, 33 a/h
charger, onboard: 24v, 5 amp
charger cord length: 6 ft (1.8m)
run time per charge: up to 2 hrs
machine weight: 124 lbs (56kg)
shipping weight :135 lbs (61kg)
dimensions (l x w x h): 30 in x 20 in x 21.7 in (77 cm x 50 cm x 55 cm)
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
In the market for a new machine? You can find quality new and reconditioned floor care equipment at one of our vendor partners:
Need a professional? We offer service both virtually and in person.
Learn more
Diagrams
- View all diagrams
- - Frequently Replaced Parts
- - Batteries, Brushes, And Chargers
- - Commonly Asked For Parts
- - Pad Holders
- Brush and Skirt Assembly
- Brush Deck Assembly
- Complete Assembly
- Electrical Assembly
- Handle Control Assembly
- Pads
- Recovery Tank Assembly
- Solution Tank Assembly
- Squeegee Assembly
- Wiring Diagram
