A flexible and easy to use solution for both daily maintenance and difficult restoration work will change the way you maintain your facility.

Flexible Cleaning
The Clarke Focus II Rider lets you easily satisfy the job at hand. Available with a 28 or 34 inch disc deck or a 28 inch BOOST deck, the Focus II Rider can easily clean university entryways or remove floor finish in healthcare facility hallways. A large 31 gallon tank and low solution flow rates result in up to 155 minutes of continuous scrubbing without a dump and refill, while increased down pressure (up to 220 pounds) allows for one pass cleaning.

Easy Operation
Featuring an open machine design, you can access the Focus II Rider driver compartment from left or right and quickly modify the tools-free adjustable seat for maximum comfort. Offering best-in-class maneuverability and water pickup, the Focus II Rider's turning radius is ideal for cleaning tight spaces while its heavy-duty steel side skirts provide enhanced wiping and water containment.

BOOST Chemical-Free Floor Finish Removal
The Focus II Rider offers a 28 inch BOOST deck that will change the way you maintain your floors forever- with chemical-free floor finish removal. Say goodbye to labor intensive floor maintenance with harsh chemicals, slippery floors, and undesirable odors. The BOOST system, with its water only finish removal, is easier to use, more productive, and safer for cleaning staff then traditional floor maintenance practices- all while reducing your floor maintenance costs forever.

-Universal One-Touch™ Controls ensure easy operation
-Increased cleaning deck down pressure ensures one-pass cleaning of even heavily soiled floors
-Heavy-duty, fully-adjustable steel side skirts maximize water pickup while protecting against machine damage
-BOOST® Technology allows more sustainable cleaning and more impressive results
-Optional Chemical Mixing System ensures that every drop of chemical will be used to clean your floors exactly as directed
-Onboard battery charger eliminates downtime by ensuring continuous operation and quick maintenance
-Wide turn radius ensures cleaning even in tight spaces

Scrub head type: Disc
Cleaning path: 28 in (71 cm)
Sound pressure level (dB(A)): 68.6 dB A (IEC 60704-1)
Max. transport speed mph (km/h): 3.91 mph (6.3 kph)
Max. cleaning speed: 3.12 mph (4.8 kph)
Max. coverage per hour @ 3.12 MPH: 38,438 sq ft (3,751 sq m)
Solution tank capacity gal (l): 31 gal (117 L)
Recovery tank capacity gal (l): 31 gal (117 L)
Low flow rate: 0.33 gal/min (1.25 L/min)
Medium flow rate: 0.60 gal/min (2.27 L/min)
High flow rate: 0.80 gal/min (3.03 L/min)
Power source: 24 VDC
Brush motor hp (W): 0.64 hp (480 Watts)
Brush speed (RPM): 260 RPM
Scrub pressure - regular scrub: 90 lb (39 kg)
Scrub pressure - heavy scrub: 150 lb (65 kg)
Scrub pressure - extreme scrub: 220 lb (96 kg)
Drive motor hp (W): 1.05 hp (780 W)
Vacuum motor: 0.75 hp (560 Watts)
Sealed waterlift: 46.1 in of H2O (11.48 kPa)
Max. airflow rate (cfm): 76.5 (36 L/sec)
Min. aisle turn (cm): 63 in (160 cm) Radius
Body length: 60 in (152 cm)
Body height: 55 in (140 cm)
Body width: 30 in (76 cm)
Max. width w/o squeegee: 31.5 in (80 cm) (Doorway)
Gross weight (GVW) (KG): 1,328 lb (602.4 kg) with 175 lb operator, 310 Ah batteries, full tank
Gradeability transport % (DEG): 7.1 %, 12.5 degrees
Max. PSI: 175 PSI (12.3 kg/sq cm) Full tank and 200 lb rider
Agency approval: CSA, ETL Canada and US
Squeegee width: 32.6 in (83 cm)
Max. weight w/o batteries: 547 lb (257.6 kg)
Gradeability - Cleaning: 4.5%, 7.9 degrees
