Maximize floor cleaning performance and simplicity the long list of floor cleaning innovations built in to the Clarke Focus II MicroRider starts with it's low-profile, SafetyGlide™ Deck. This innovative cleaning deck not only prevents water marks with 100% water pickup, but also eliminates the need for side skirts necessary with other riders. It features a unique, spring-loaded safety design, so you don't have to worry about accuracy or accidental contact during edge cleaning: The deck ensures precise edge cleaning with no additional detail mopping.
BOOST® technology allows the Clarke Focus II MicroRider to reduce your chemical and water use by up to 70%, extend cleaning pad life by 40% and remove floor finishes with chemicals. Low profile, SafetyGlide™ Deck eliminates irritating watermarks and the need for costly side skirts. Wide 26 or 28 inch cleaning path cuts cleaning time in large cleaning areas. Universal one-touch controls and solution level indicator ensure easy operation. Safe-T-Steering™ reduces speed on turns, keeping operators safer. Optional chemical mixing system ensures precise mixing of water and chemicals for optimal, more sustainable results. Unique, durable squeegee design ensures excellent water pickup and drier floors.
Scrub head type: Dual Disc
Scrub path: 26 in (660 mm)
Capacity: 21 gal (80 L)
Productivity at 3.7 mph: 42,328 sq ft/hr (3,932 sq m/hr)
Max. speed: 3.7 mph (6 km/hr)
Brush pressure: Setting 1 = 65 lb (30 kg) / Setting 2 = 105 lb (48 kg)
Brush speed (RPM): 230 RPM
Brush motor (W): 0.54 hp (400 W)
Vacuum motor: 0.56 hp (420 W)
Vacuum airflow: 55.3 CFM (26.1 L/Sec)
Vacuum waterlift: 57 in (14.2 KPA)
Water flow (l/min.): 0 - 0.8 gpm (0 - 3.0 L/min)
Min. turn-around aisle width (CM): 59 in (150 cm)
Max. ramp climbing: 16 degrees
Squeegee width: 35 in (89 cm)
Voltage (V): 24 VDC
Power source: (4) 6 Volt batteries (wet acid and AGM maintenance-free)
Battery charger: 24 VDC onboard
Maximum running time :3.5 hours
Dimensions (W/O Squeegee): 53.5 x 26.4 x 48.4 in (136 x 67 x 123 cm)
Weight without batteries: 385.8 lb (175 kg) w/ empty tanks
Max. weight (full solution tank and largest batteries): 983.2 lb (446 kg)
Approvals: ETL, CSA
Ip protection class: IPX3
PSI Front Tire with Operator and Full Tank: 72.5 psi (0.5 N/sq mm)
PSI Rear Tires with Operator and Full Tank: 130.5 psi (0.9 N/ sq mm)
Sound pressure level EN ISO 11201: 1995: High Setting = 65 dB A / Low Setting = 61 dB A
Clarke (Alto) FOCUS II MICRO Parts and Support
everything you need in a compact rider the clarke® focus® ii microrider™ floor scrubber is a small, easily maneuverable scrubber designed to clean areas inaccessible to larger riders. yet, with a 26- or 28-inch deck, its wide scrubbing path can cut cleaning time in larger areas.
maximize floor cleaning performance and simplicity the long list of floor cleaning innovations built in to the clarke focus ii microrider starts with it's low-profile, safetyglide™ deck. this innovative cleaning deck not only prevents water marks with 100% water pickup, but also eliminates the need for side skirts necessary with other riders. it features a unique, spring-loaded safety design, so you don't have to worry about accuracy or accidental contact during edge cleaning: the deck ensures precise edge cleaning with no additional detail mopping.
boost® technology allows the clarke focus ii microrider to reduce your chemical and water use by up to 70%, extend cleaning pad life by 40% and remove floor finishes with chemicals. low profile, safetyglide™ deck eliminates irritating watermarks and the need for costly side skirts. wide 26 or 28 inch cleaning path cuts cleaning time in large cleaning areas. universal one-touch controls and solution level indicator ensure easy operation. safe-t-steering™ reduces speed on turns, keeping operators safer. optional chemical mixing system ensures precise mixing of water and chemicals for optimal, more sustainable results. unique, durable squeegee design ensures excellent water pickup and drier floors.
scrub head type: dual disc
scrub path: 26 in (660 mm)
capacity: 21 gal (80 l)
productivity at 3.7 mph: 42,328 sq ft/hr (3,932 sq m/hr)
max. speed: 3.7 mph (6 km/hr)
brush pressure: setting 1 = 65 lb (30 kg) / setting 2 = 105 lb (48 kg)
brush speed (rpm): 230 rpm
brush motor (w): 0.54 hp (400 w)
vacuum motor: 0.56 hp (420 w)
vacuum airflow: 55.3 cfm (26.1 l/sec)
vacuum waterlift: 57 in (14.2 kpa)
water flow (l/min.): 0 - 0.8 gpm (0 - 3.0 l/min)
min. turn-around aisle width (cm): 59 in (150 cm)
max. ramp climbing: 16 degrees
squeegee width: 35 in (89 cm)
voltage (v): 24 vdc
power source: (4) 6 volt batteries (wet acid and agm maintenance-free)
battery charger: 24 vdc onboard
maximum running time :3.5 hours
dimensions (w/o squeegee): 53.5 x 26.4 x 48.4 in (136 x 67 x 123 cm)
weight without batteries: 385.8 lb (175 kg) w/ empty tanks
max. weight (full solution tank and largest batteries): 983.2 lb (446 kg)
approvals: etl, csa
ip protection class: ipx3
psi front tire with operator and full tank: 72.5 psi (0.5 n/sq mm)
psi rear tires with operator and full tank: 130.5 psi (0.9 n/ sq mm)
sound pressure level en iso 11201: 1995: high setting = 65 db a / low setting = 61 db a
maximize floor cleaning performance and simplicity the long list of floor cleaning innovations built in to the clarke focus ii microrider starts with it's low-profile, safetyglide™ deck. this innovative cleaning deck not only prevents water marks with 100% water pickup, but also eliminates the need for side skirts necessary with other riders. it features a unique, spring-loaded safety design, so you don't have to worry about accuracy or accidental contact during edge cleaning: the deck ensures precise edge cleaning with no additional detail mopping.
boost® technology allows the clarke focus ii microrider to reduce your chemical and water use by up to 70%, extend cleaning pad life by 40% and remove floor finishes with chemicals. low profile, safetyglide™ deck eliminates irritating watermarks and the need for costly side skirts. wide 26 or 28 inch cleaning path cuts cleaning time in large cleaning areas. universal one-touch controls and solution level indicator ensure easy operation. safe-t-steering™ reduces speed on turns, keeping operators safer. optional chemical mixing system ensures precise mixing of water and chemicals for optimal, more sustainable results. unique, durable squeegee design ensures excellent water pickup and drier floors.
scrub head type: dual disc
scrub path: 26 in (660 mm)
capacity: 21 gal (80 l)
productivity at 3.7 mph: 42,328 sq ft/hr (3,932 sq m/hr)
max. speed: 3.7 mph (6 km/hr)
brush pressure: setting 1 = 65 lb (30 kg) / setting 2 = 105 lb (48 kg)
brush speed (rpm): 230 rpm
brush motor (w): 0.54 hp (400 w)
vacuum motor: 0.56 hp (420 w)
vacuum airflow: 55.3 cfm (26.1 l/sec)
vacuum waterlift: 57 in (14.2 kpa)
water flow (l/min.): 0 - 0.8 gpm (0 - 3.0 l/min)
min. turn-around aisle width (cm): 59 in (150 cm)
max. ramp climbing: 16 degrees
squeegee width: 35 in (89 cm)
voltage (v): 24 vdc
power source: (4) 6 volt batteries (wet acid and agm maintenance-free)
battery charger: 24 vdc onboard
maximum running time :3.5 hours
dimensions (w/o squeegee): 53.5 x 26.4 x 48.4 in (136 x 67 x 123 cm)
weight without batteries: 385.8 lb (175 kg) w/ empty tanks
max. weight (full solution tank and largest batteries): 983.2 lb (446 kg)
approvals: etl, csa
ip protection class: ipx3
psi front tire with operator and full tank: 72.5 psi (0.5 n/sq mm)
psi rear tires with operator and full tank: 130.5 psi (0.9 n/ sq mm)
sound pressure level en iso 11201: 1995: high setting = 65 db a / low setting = 61 db a
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
In the market for a new machine? You can find quality new and reconditioned floor care equipment at one of our vendor partners:
Need a professional? We offer service both virtually and in person.
Learn more
Diagrams
- View all diagrams
- - Batteries, Brushes and Charger
- - Commonly Asked For Parts
- - Pad Holders
- Basket Assembly
- Battery Charger Assembly
- Boost Brush Deck Assembly
- Brushes Deck Assembly
- Chassis Assembly
- Chemical Mixing Assembly
- Column Assembly
- Drive Wheel Assembly
- Electrical Components Assembly
- Magic Deck Assembly
- Magic Deck Boost Brush Assembly
- Noise Reduction Assembly
- Pads - 13 inch
- Pads - 14 x 28 inch
- Recovery Tank Assembly
- Solution Assembly
- Solution Tank Assembly
- Square Brushes 14 x 28
- Squeegee Assembly
- Squeegee Raising Assembly
- Steering Assembly
- Steering Wheel Support Assembly
- Wiring Diagram
Bulletins
- Alto Clarke Focus II Rider Delta Q Onboard Charger Interlock Failure
- Onboard battery charger failure
- TSS Bulletin - Charger conversion options - Clarke Focus II Micro and 26D
