•Extra-wide 32 inch cleaning path
•Available without batteries or with 250 Ah batteries and shelf charger •Easy-to-use fingertip controls
•370 W traction drive system
•Rounded squeegee for easy and complete solution pick-up
Scrub Path / Pad Diameter 32 in (80 cm) / 2-16 in (40.6 cm)
Solution Tank 30 gal (115 L)
Recovery Tank 28 gal (106 L)
Pad Pressure Variable, up to 200 lb (91 kg)
Pad Speed 200 rpm
Squeegee Width 40 in (102 cm)
Cleaning Productivity (Max) 34,560 ft2 /hr (3,211 m2 /hr)
Power Source (6) 6 V batteries, 250 Ah with 25 amp shelf charger
Brush Motor 1 hp, 740 W
Vac Motor 3 stage, 73 in (186 cm) waterlift
Drive System 0.5 hp transaxle
Speed Control Variable forward/reverse
Dimensions (L x W x H) 66.5 in (169 cm) x 41.3 in (105 cm) x 42.9 in (109 cm)
Weight Without Batteries: 441 lb (200 kg)
Shipping Weight Without Batteries: 631 lb (286 kg)
Clarke (Alto) CA90 32T Parts and Support
Featuring variable speed control and pad pressure, as well as forward/reverse motion, the monstrous Clarke CA90 32T can cover over 34,560 square feet per hour and apply up to 200 pounds of down pressure. On top of that, its easy-to-use fingertip controls make it simple and intuitive even for new operators. The CA90 32T has a productive 32 inch cleaning path that makes it an ideal solution for large environments that require regular, aggressive cleaning such as schools, malls, hospitals, airports, hotels and more.
•Extra-wide 32 inch cleaning path
•Available without batteries or with 250 Ah batteries and shelf charger •Easy-to-use fingertip controls
•370 W traction drive system
•Rounded squeegee for easy and complete solution pick-up
Scrub Path / Pad Diameter 32 in (80 cm) / 2-16 in (40.6 cm)
Solution Tank 30 gal (115 L)
Recovery Tank 28 gal (106 L)
Pad Pressure Variable, up to 200 lb (91 kg)
Pad Speed 200 rpm
Squeegee Width 40 in (102 cm)
Cleaning Productivity (Max) 34,560 ft2 /hr (3,211 m2 /hr)
Power Source (6) 6 V batteries, 250 Ah with 25 amp shelf charger
Brush Motor 1 hp, 740 W
Vac Motor 3 stage, 73 in (186 cm) waterlift
Drive System 0.5 hp transaxle
Speed Control Variable forward/reverse
Dimensions (L x W x H) 66.5 in (169 cm) x 41.3 in (105 cm) x 42.9 in (109 cm)
Weight Without Batteries: 441 lb (200 kg)
Shipping Weight Without Batteries: 631 lb (286 kg)
•Extra-wide 32 inch cleaning path
•Available without batteries or with 250 Ah batteries and shelf charger •Easy-to-use fingertip controls
•370 W traction drive system
•Rounded squeegee for easy and complete solution pick-up
Scrub Path / Pad Diameter 32 in (80 cm) / 2-16 in (40.6 cm)
Solution Tank 30 gal (115 L)
Recovery Tank 28 gal (106 L)
Pad Pressure Variable, up to 200 lb (91 kg)
Pad Speed 200 rpm
Squeegee Width 40 in (102 cm)
Cleaning Productivity (Max) 34,560 ft2 /hr (3,211 m2 /hr)
Power Source (6) 6 V batteries, 250 Ah with 25 amp shelf charger
Brush Motor 1 hp, 740 W
Vac Motor 3 stage, 73 in (186 cm) waterlift
Drive System 0.5 hp transaxle
Speed Control Variable forward/reverse
Dimensions (L x W x H) 66.5 in (169 cm) x 41.3 in (105 cm) x 42.9 in (109 cm)
Weight Without Batteries: 441 lb (200 kg)
Shipping Weight Without Batteries: 631 lb (286 kg)
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
In the market for a new machine? You can find quality new and reconditioned floor care equipment at one of our vendor partners:
Need a professional? We offer service both virtually and in person.
Learn more
Diagrams
- View all diagrams
- - Frequently Replaced Parts
- - Batteries, Brushes, and Chargers
- - Commonly Asked For Parts
- - Pad Holders
- - Pads - 16 inch
- Control Housing Assembly
- Main Frame and Drive Assembly
- Recovery Tank Assembly
- Scrub Deck Assembly
- Scrub Deck Lift Assembly
- Solution Control Assembly
- Solution Tank Assembly
- Squeegee and Squeegee Lift Assembly
- Wiring Diagram
